HAIWANGXING
HAIWANGXING T9W
Minimalist Dual-Glass Design
Wide-Body Chassis
Advanced Cooling Support, Supports Up to 13 Cooling Fans
Built-in USB Type-C Port
specifications
| Product Type | |
| Color | White |
| Front Panel | Glass |
| Left Side Panel Material | Glass |
| Product Dimensions (mm) | L536xW245xH417mm |
| Metal Parts Dimensions (mm) | L536xW245xH390mm |
| Compatible Motherboards | E-ATX/ATX/MicroATX |
| Rear I/O Motherboard Support | No |
| Optical Drive Bays | No |
| 3.5" HDD Bays | 1 |
| SSD Mounting Slots | 2 |
| Water Cooling Support | Rear side：120mm Top side：480mm/420mm |
| Fan Mounting Positions | Front side：12cmx2 Side face：12cmx2 Rear side：12cmx 1/14cmx1 Top side：12cmx4/14cmx3 Bottom side: 12cmx4/14cmx2 |
| CPU Cooler Height Limit | 180mm |
| GPU Length Limit | 340mm |
| Number of PCI Slots | 7 |
| PSU Position | Bottom |
| PSU Length Limit | 220mm |
| USB2.0 | No |
| USB3.0 | 2 |
| USB-C | 1 |
| Audio Ports | Mic和Spk 2--1 |
| Outer Carton Dimensions (mm) | L585xW315xH495mm |
| Net Weight (Kg) | 10.2Kg |
| Gross Weight (Kg) | 11.8Kg |
