GW-950ZG (Box)

Intel ATX 3.1

PCIe 5.0 Interface

specifications
Altitude ≤5000
100% Load Efficiency ≥85%
Cable type Fixed Cable
ATX 24PIN Cable Length 500
CPU Cable Length 600~150
CPU Connectors 2
PCI-E 6+2 Cable Length 420~150
PCI-E 6+2 Connectors 2
PCIe 5.1 Cable Length 520
PCIe 5,1. Connectors 1
Watt 850
SATA Connectors 2
L4P Connectors 2
Efficiency CQCI
ATX Rev ATX3.1
Description
Input Volage
S4P Connectors 0
Dimension (L)*(W)*(H)(mm) Non_Chasis 140*150*86
Fan Dimension 12
Safety CCC、CQCI
Switch
Model List
Series Title Watt Efficiency ATX Rev Description Input Volage Dimension (L)*(W)*(H)(mm) Non_Chasis Fan Dimension Safety Switch Altitude 100% Load Efficiency Cable type ATX 24PIN Cable Length CPU Cable Length CPU Connectors PCI-E 6+2 Cable Length PCI-E 6+2 Connectors PCIe 5.1 Cable Length PCIe 5,1. Connectors SATA Connectors L4P Connectors S4P Connectors Data Download Certification Standards Technical Manual
Smart Manager​
Smart Manager​
-
-
-
GW-950ZG (Box)
GW-950ZG (Box)
 850 CQCI ATX3.1 140*150*86 12 CCC、CQCI ≤5000 ≥85% Fixed Cable 500 600~150 2 420~150 2 520 1 2 2 0
GW-850ZG (Box)
GW-850ZG (Box)
 750 CQCI ATX3.1 140*150*86 12 CCC、CQCI ≤5000 ≥85% Fixed Cable 500 600~150 2 420~150 2 520 1 2 2 0
GW-725ZG (Box)
GW-725ZG (Box)
 625 140*150*86 12 CCC ≤5000 ≥84% Fixed Cable 500 600~150 2 450~150 2 4 2 0
GW-600ZG (Box)
GW-600ZG (Box)
 500 140*150*86 12 CCC ≤5000 ≥74% Fixed Cable 500 600~150 2 450~150 2 4 2 0
