小金钢

​​Little Titanium​

GW-375
Anti-Moisture Anti-Insect Anti-Dust
specifications
Altitude ≤5000
100% Load Efficiency ≥66%
Cable type Fixed Cable
ATX 24PIN Cable Length 500
CPU Cable Length 580
CPU Connectors 1
PCI-E 6+2 Cable Length 450
PCI-E 6+2 Connectors 1
PCIe 5.1 Cable Length
PCIe 5,1. Connectors
Watt 275
SATA Connectors 4
L4P Connectors 2
Efficiency
ATX Rev
Description
Input Volage
S4P Connectors 0
Dimension (L)*(W)*(H)(mm) Non_Chasis 140*150*86
Fan Dimension 12
Safety CCC
Switch
Model List
Series Title Watt Efficiency ATX Rev Description Input Volage Dimension (L)*(W)*(H)(mm) Non_Chasis Fan Dimension Safety Switch Altitude 100% Load Efficiency Cable type ATX 24PIN Cable Length CPU Cable Length CPU Connectors PCI-E 6+2 Cable Length PCI-E 6+2 Connectors PCIe 5.1 Cable Length PCIe 5,1. Connectors SATA Connectors L4P Connectors S4P Connectors Data Download Certification Standards Technical Manual
​​Little Titanium​
-
-
-
GW-825
725W ATX3.1 140*150*86 12 CCC ≤5000 ≥85% Fixed Cable 500 650+100 2 450+100 2 520 1 2 2
GW-625
525 ATX12V2.31 140*150*86 12 CCC ≤5000 ≥74% Fixed Cable 500 650+100 2 420+100 2 2 2
GW-425
325 140*150*86 12 CCC ≤5000 ≥66% Fixed Cable 500 580 1 450 1 3 2 0
GW-375
275 140*150*86 12 CCC ≤5000 ≥66% Fixed Cable 500 580 1 450 1 4 2 0
GW-330 V01
230 140*150*86 12 CCC ≤5000 ≥65% Fixed Cable 500 580 1 0 0 2 2 0
