TITAN
TITAN
GW-TF750(90+)（WHITE）
Single +12V high-current rail;
Supports 100–240V full-range input.；
80 PLUS Gold Certified and CE for Efficiency.；
"Innovative Active PFC + LLC + Synchronous Rectification (SR) Topology Architecture;
DC-to-DC Conversion for 5V/3.3V;
Compact design, powerful performance, and fully modular—built to meet the demands of high-end gamers.;
Compatible with SFX cases for space-saving installation.;
Low noise with intelligent silent operation.。
specifications
| Efficiency Certification | 80PLUS（GOLD） |
| Product Part Number | 5185017 |
| Promotional Name | TF750 Gold Modular（White） |
| ATX Version | ATX2.31 |
| Power | 750W |
| Power Supply Dimensions | 125*100*63.5 |
| Fan Size | 90mm |
| AC Connector | |
| Input Voltage Range | 100V-240V |
| Color | White |
| Cable Output Type | Modular |
| Warranty Period | 7 Years |
| Carton Specification | 6 units per carton |
| Certification | CCC，CE |
| Product Selling Points | |
| ATX 24-PIN Cable Length | 300 |
| CPU Cable Length | 400 |
| Number of CPU Connectors | 2 |
| PCI-E 6+2 Cable Length | 400 |
| Number of PCI-E 6+2 Connectors | 2 |
| PCIe 5.1 Cable Length | / |
| Number of PCIe 5.1 Connectors | / |
| SATA Cable Length | 100+115+115+115 |
| Number of SATA Connectors | 8 |
| Number of SATA 3.3 Connectors | |
| L4P Cable Length | 100+115+115+115 |
| Number of L4P Connectors | 4 |
| Remarks |
