GW-ATX750BL G7MWG
Single +12V high-current rail supports 100–240V full-range input for global compatibility.;
Certified with 80 PLUS Gold and CE standards.；
Zero RPM fan mode: the cooling fan shuts off completely under low to moderate loads.;
"Equipped with high-quality Japanese capacitors and an advanced Active PFC + LLC + SR topology for superior performance and reliability.;
DC-DC design for 5V and 3.3V rails ensures more stable current and flexible power distribution.；
NTC and two-stage EMI filtering enhance safety and reliability by preventing damage to internal components. ;
Fully modular black flat steel extended cables deliver a premium, high-end aesthetic.；
Complies with Intel ATX 3.1 and PCIe 5.1 standards.。
specifications
| Efficiency Certification | 80PLUS （GOLD） |
| Product Part Number | 5194871 |
| Promotional Name | G7 Gold Modular（ATX3.1）White |
| ATX Version | ATX3.1 |
| Power | 750W |
| Power Supply Dimensions | 140*150*86 |
| Fan Size | 140mm |
| AC Connector | |
| Input Voltage Range | 100V-240V |
| Color | 白 |
| Cable Output Type | Modular |
| Warranty Period | 7 Years |
| Carton Specification | 4 units per carton |
| Certification | CCC，CE |
| Product Selling Points | |
| ATX 24-PIN Cable Length | 610 |
| CPU Cable Length | 650 |
| Number of CPU Connectors | 2 |
| PCI-E 6+2 Cable Length | 600 |
| Number of PCI-E 6+2 Connectors | 4 |
| PCIe 5.1 Cable Length | 600 |
| Number of PCIe 5.1 Connectors | 1 |
| SATA Cable Length | 500 |
| Number of SATA Connectors | 4 |
| Number of SATA 3.3 Connectors | |
| L4P Cable Length | 600+100 |
| Number of L4P Connectors | 8 |
| Remarks |
